1416359 24 Pin Connector Set: Uses, Specifications & Replacement Guide

The 1416359 24-pin connector is a 24-position industrial connector set designed to provide secure and organized electrical connections. It features a push-in connection system, die-cast aluminum housing, and IP66/IP67 protection. Turbine Parts Specialist lists the 1416359 SET, CONNECTOR, 24 PIN for GE TM/LM 2500 turbine applications, making accurate identification important when sourcing a replacement.

What Is the 1416359 24 Pin Connector?

The 1416359 SET is a 24-position connector assembly from the Phoenix Contact HC-B series. Its product designation is HC-STA-B24PT-BWD-LS-M32-ELCAL, and it is designed for industrial electrical connections.

One useful feature is its die-cast aluminum housing, which provides a sturdy enclosure around the connection points. In addition, the connector has a lateral cable outlet and uses a push-in connection method, allowing conductors to be terminated without relying on traditional screw connections.

For turbine-related maintenance, the part number is especially useful. Turbine Parts Specialist lists the 1416359 SET, CONNECTOR, 24 PIN within its GE TM/LM 2500 turbine parts selection. Therefore, checking the part number before ordering is a practical first step.

What Are the Specifications of 1416359?

Understanding the technical specifications helps ensure that the connector is correctly matched to the application.

Specification	Details
Part Number	1416359
Connector Type	Connector Set
Series	HC-B
Positions	24
Connection Method	Push-in
Connection Profile	24+PE
Rated Voltage	500 V
Rated Current	16 A
Conductor Size	0.14–2.5 mm²
AWG Range	26–14
Housing Material	Die-cast aluminum
Protection Rating	IP66/IP67
Cable Outlet	Lateral
Cable Diameter	15–21 mm
Operating Temperature	-40°C to 100°C
Locking Type	Latch

These specifications distinguish the 24-pin electrical connector from other connectors that may have a similar number of positions but different electrical or mechanical characteristics.

What Is the 1416359 Connector Used For?

The main purpose of the 1416359 24-pin connector is to provide multiple electrical connection points through one protected connector assembly.

A 24-position design can help organize several conductors in industrial equipment while reducing the need for separate connection points. The aluminum housing also provides mechanical protection, while the IP66/IP67 rating is intended for demanding environments.

For GE TM/LM 2500 turbine applications, Turbine Parts Specialist lists this connector as part of its available turbine components. As a result, the 1416359 part number can be useful when identifying a required component during maintenance or replacement.

Why Is the Correct 24 Pin Connector Important?

Not every 24-pin industrial connector is interchangeable. Connectors with the same number of positions can have different housings, connection methods, cable outlets, mounting arrangements, and electrical ratings.

Before selecting a replacement, compare the following:

• Exact part number
• Number of positions
• Connection method
• Connector configuration
• Cable outlet direction
• Cable diameter
• Conductor size
• Voltage and current ratings
• Housing material
• Protection rating
• Mounting requirements

As a result, matching the pin count alone is not enough to confirm compatibility.

How Do You Identify a 1416359 Replacement?

Start with the existing connector. Look for the part number or other identification markings on the component. If the marking is difficult to read, equipment manuals, maintenance records, and parts lists may provide additional information.

If the existing component is identified as 1416359, compare its specifications with the replacement before placing an order. For GE TM/LM 2500 equipment, it is also important to confirm that the connector matches the specific turbine configuration.

For example, another connector may have 24 positions but a different housing or connection system. Even though it looks similar, it may not be an appropriate substitute.

How Should the Connector Be Replaced?

Connector replacement should be carried out by qualified personnel and according to the relevant equipment maintenance procedures. Before removing the old component, take time to document the wiring arrangement and verify the replacement part.

The process generally involves:

1. Confirm the part number and connector configuration.
2. Safely isolate the relevant equipment.
3. Record the position of each conductor.
4. Inspect cables, terminals, seals, and mounting points.
5. Install the replacement connector correctly.
6. Check each electrical connection.
7. Make sure the housing and locking mechanism are secure.
8. Complete the required electrical and operational checks.

Most importantly, follow the equipment manufacturer’s approved procedures rather than relying on a generic replacement process.

Where Can You Source the 1416359 Set?

Turbine Parts Specialist lists the 1416359 SET, CONNECTOR, 24 PIN as part of its GE TM/LM 2500 turbine parts selection. When sourcing this component, providing the exact part number and equipment information can make identification easier.

If you need a 1416359 24-pin connector for turbine maintenance or replacement, our team can assist with component identification and sourcing.

Wind Up

The 1416359 24-pin connector is a 24-position industrial connector set with push-in connections, a die-cast aluminum housing, IP66/IP67 protection, and 16 A/500 V ratings. Its exact configuration makes proper part identification essential when replacing an existing connector.

For GE TM/LM 2500 applications, always verify the 1416359 SET, CONNECTOR, 24 PIN part number and complete connector configuration before ordering. With the correct information, sourcing the right turbine component becomes much easier. Turbine Parts Specialist can help with component identification and sourcing for your specific turbine requirements.
